A proven bedliner former, two line types and one team from sheet to trimmed liner.
Modelled for a full-size HDPE bedliner, two lanes, three shifts.
Base and Pro
Cut HDPE sheets are loaded automatically into the former. Heating and vacuum forming produce the liner shell.
Pro gantry
Base moves liners by hand. Pro uses an overhead gantry to carry the liner between stations.
Pro ShearBot™
Pro cuts off the margin while the liner is warm. Base removes edges in the robot trim cell.
Pro Cool-off Boxes™
Base cools the liner on the tool. Pro holds it in a Cool-off Box™ away from the former.
Robot cells trim holes and final edges. The trimmed liners are stacked or placed on pallets.
Modelled for a full-size HDPE bedliner, two lanes, three shifts, 85% running time. Your part sets the final numbers in a Part Study™.
The PF1-Bolt former is built on the bedliner machine we designed for HDPE pickup liners. It has run in production at an automotive supplier in India since 2023.
Machinecraft will review your proposed forming route, identify information still needed, discuss relevant machine options and downstream scope, and agree the next engineering step.
