PF1 machine gallery

PF1 equipment, workshop and installation images, collected separately from the current machine ranges. Each image keeps its original view, lighting and machine details.

Browse current machine ranges

PF1 with sheet table in a yellow-column bay — Forming press and sheet-loading bay
PF1 with sheet table in a yellow-column bay.

People standing at the control panel of a compact white Machinecraft machine in a workshop. — At the machine controls
At the controls of a compact Machinecraft machine, October 2026.

Interior view of a PF1 forming area with a heater bank and numbered machine frame. — Heater bank and forming area
View into a PF1 forming area, showing the heater bank and numbered machine frame.

A hand holding a thermal camera in front of an illuminated machine heater array. — Thermal inspection of the heater
Thermal imaging during a machine heater check, September 2024.

Workers using a chain hoist to position a large assembly inside an unfinished machine frame. — Machine assembly in the workshop
Machine assembly using a chain hoist. Archive photograph, February 2021.

People working around a Machinecraft machine with access stairs and yellow rails during installation in Japan. — Machine during installation
Machinecraft equipment during the Japan installation project, August 2026.

Machinecraft PF1 in a sunlit hall, three-quarter — PF1 in a working hall
Machinecraft PF1 in a sunlit hall, three-quarter.

Catalogue three-quarter of a white PF1 — Catalogue equipment view
Catalogue three-quarter of a white PF1.

These are equipment reference images, not current model specifications. Browse current machine ranges.
