Vacuum Forming & Thermoforming Machines.
Machinecraft manufactures custom automatic thermoforming machines: heavy gauge sheet-fed in Classic (PF1-C) and Advanced (PF1-X) variants, roll-fed form-cut-stack (FCS), and roll-fed pressure forming (AM). Every machine is tailor-made to your specific production requirements.
PF1 Classic Series
Pneumatic Cut-Sheet Vacuum Forming Machine
The PF1 Classic is the workhorse of Machinecraft's heavy-gauge thermoforming lineup. Fully pneumatic with closed-chamber design, pre-blow bubble, and zero-sag control. Ideal for manufacturers who need reliable, cost-effective vacuum forming for industrial parts, automotive panels, bathtubs, signage, and more. Available in 12 standard sizes from 1000x800mm to 3000x2000mm.
Machine Features
Closed Chamber Design
Air-sealed chamber with pre-blow bubble and zero sag control for consistent forming of heavy gauge sheets
Pneumatic Drives
Reliable pneumatic cylinders with rack & pinion for forming platen, plug assist, clamp frame, and heater oven movements
Sandwich Heating
Top and bottom IR heating with ceramic infrared elements, quartz elements, or halogen elements. SSR solid-state control, PID per zone via HMI touchscreen
Fixed Welded Clamp Frames
Sturdy welded frames for consistent clamping. One frame supplied per machine, additional frames available for different sheet sizes
PLC with Touchscreen HMI
Recipe storage, heater zone control, timing, diagnostics, and safety interlocks on a color touchscreen
Custom Built
Every machine is tailor-made to your exact specifications — forming area, draw depth, heater configuration, and accessories
12 Standard Models
| Model | Forming Area | Max Draw | Sheet Thickness |
|---|---|---|---|
| PF1-C-1008 | 1000 x 800 mm | 400 mm | 2-10 mm |
| PF1-C-1208 | 1200 x 800 mm | 400 mm | 2-10 mm |
| PF1-C-1212 | 1200 x 1200 mm | 500 mm | 2-10 mm |
| PF1-C-1510 | 1500 x 1000 mm | 500 mm | 2-10 mm |
| PF1-C-1812 | 1800 x 1200 mm | 500 mm | 2-12 mm |
| PF1-C-2010 | 2000 x 1000 mm | 500 mm | 2-12 mm |
| PF1-C-2015 | 2000 x 1500 mm | 500 mm | 2-12 mm |
| PF1-C-2020 | 2000 x 2000 mm | 600 mm | 2-12 mm |
| PF1-C-2412 | 2400 x 1200 mm | 500 mm | 2-12 mm |
| PF1-C-2515 | 2500 x 1500 mm | 600 mm | 2-12 mm |
| PF1-C-3015 | 3000 x 1500 mm | 600 mm | 2-12 mm |
| PF1-C-3020 | 3000 x 2000 mm | 800 mm | 2-12 mm |
Compatible Materials
Applications
PF1-X Series
Servo-Driven Advanced Vacuum Forming Machine
The PF1-X is Machinecraft's advanced servo-driven thermoforming machine with the European concept of closed chamber design to allow pre-blow bubble & zero sag control. Equipped with servo motor driven forming table, universal motorised aperture setting, IR heating (ceramic infrared elements, quartz elements, or halogen elements) with pyrometer, rotary vane vacuum with proportional servo valve, and programmable speed profiles. Optional automatic sheet loading and unloading for fully automated production cycles. Standard sizes range from 1000x600mm to 4000x2000mm, with XL models up to 6000x2200mm.
Machine Features & Options
Servo Motor Driven Forming Table
Servo motor driven with gearbox for variable speed, acceleration, and deceleration profiles — can stop at any position for precise forming
Universal Motorised Aperture
Motorised window plate adjustment in both axes via touchscreen. Sheet size changeover in under 5 minutes, no manual adjustment
IR Heating + Pyrometer
Choice of IR Ceramic (long-wave, 500W top / 400W bottom), IR Quartz, or Halogen heaters with SSR control and pyrometer for real-time sheet temperature monitoring
Rotary Vane Vacuum + Servo Valve
Oil-lubricated rotary vane pumps with proportional servo valve for multi-step vacuuming and automatic air-ejection demoulding
Air-Locked Front Door
Air cylinder locked doors for safety and consistent chamber sealing during closed-chamber forming
Centralized Ducted Cooling
High-CFM blower with ducting manifold, flexible hoses, and fixed nozzles for uniform cooling across the entire forming area
Optional Automatic Loading & Unloading
Servo-driven vacuum pad sheet loader picks sheets from a stack and feeds them into the machine automatically. Automatic part unloader removes formed parts and places them on a conveyor or stacking system for continuous, hands-free production cycles.
10 Standard Models
| Model | Forming Area | Max Tool Height | Heater Power |
|---|---|---|---|
| PF1-X-1012 | 1200 x 1000 mm | 400 mm | 35 kW |
| PF1-X-1015 | 1500 x 1000 mm | 400 mm | 45 kW |
| PF1-X-1215 | 1500 x 1200 mm | 500 mm | 55 kW |
| PF1-X-1520 | 2000 x 1500 mm | 500 mm | 75 kW |
| PF1-X-1525 | 2500 x 1500 mm | 550 mm | 95 kW |
| PF1-X-1528 | 2800 x 1500 mm | 550 mm | 110 kW |
| PF1-X-3020 | 3000 x 2000 mm | 650 mm | 135 kW |
| PF1-X-3520 | 3500 x 2000 mm | 650 mm | 160 kW |
| PF1-X-4020 | 4000 x 2000 mm | 700 mm | 185 kW |
Compatible Materials
Applications
PF1 Classic vs PF1-X Pro.
Both machines share the same closed-chamber design and forming principle. The PF1-X adds servo drives, motorised aperture, ceramic heating, and advanced vacuum control for higher precision and faster changeovers.
| Feature | PF1 Classic | PF1-X Pro |
|---|---|---|
| Forming Table Drive | Pneumatic (4x cylinders + rack & pinion) | Servo Motors (variable speed) |
| Clamp Frame | Fixed welded (manual changeover ~15 min) | Universal Motorised Aperture (auto < 5 min via touchscreen) |
| Front Door | Manual turn-able locks | Air cylinder locked |
| Vacuum System | Single-stage centrifugal fans | Rotary vane pump + servo valve (multi-step) |
| Cooling | Centrifugal fans (4 pcs) | Centralized ducted blower system |
| Heating | IR Quartz | IR Ceramic, Quartz, or Halogen + Pyrometer |
| HMI | 7" color touchscreen | Advanced touchscreen with recipe management |
| Size Range | 1000x800 to 3000x2000 (12 models) | 1000x600 to 6000x2200 (15 models incl. XL) |
Both series are custom-built to order. Contact us for a detailed quotation based on your specific requirements.
PF1-X XL Series.
Forming areas up to 6000 x 2200 mm
Machinecraft's XL and XXL vacuum forming machines are engineered for the largest thermoforming applications in the world. With forming areas exceeding 4500mm, these machines produce full-size automotive panels, bathtubs, spas, large signage, tractor body parts, and deep-drawn pickup truck bed-liners — all in a single forming cycle.
PF1-X XL machine with ambulance interior mold in factory
5 XL Models
| Model | Forming Area | Max Tool Height | Heater Power |
|---|---|---|---|
| PF1-XL-3020 | 3000 x 2000 mm | 800 mm | 230 kW |
| PF1-XL-4022 | 4000 x 2200 mm | 1000 mm | 333 kW |
| PF1-XL-3030 | 3000 x 3000 mm | 1000 mm | 346 kW |
| PF1-XL-6022 | 6000 x 2200 mm | 1000 mm | 480 kW |
| PF1-XL-5028 | 5000 x 2800 mm | 1000 mm | 576 kW |
XL-Specific Engineering
Closed Chamber with Pre-Blow
Bottom heater retracts to allow controlled sheet sag, then air pressure pre-stretches the sheet before mold contact, ensuring uniform wall thickness even on 1000mm deep draws across large forming areas.
Multi-Zone Infrared Heating
Individual zone control across top and bottom heater banks for precise temperature profiling — critical for HDPE and other materials with narrow forming windows.
Sheet Sag Detection
Infrared sensors continuously monitor sheet sag during heating, automatically adjusting heater output to prevent excessive sagging on extra-large sheets.
Servo-Driven Forming Platen
Programmable speed profiles for optimal sheet-to-mold contact during the forming stroke, with up to 50-ton clamping force.
XL Applications
FCS Series
Roll Fed Continuous Pressure Forming Machine
Roll fed continuous pressure forming machine with integrated forming and punching stations. Servo-driven spike chain indexing with ±0.3mm accuracy. Toggle press forming and up to 90 tonne punching force. Designed for high-volume thermoformed packaging production.
Machine Features
Dual Station Design
Separate forming and punching stations — toggle press forming + up to 90 tonne punching force
Servo Spike Chain Indexing
1/2" duplex spiked chain with ±0.3mm accuracy, water cooled chain rails
Sandwich Heating
Roll-out oven design with top and bottom IR heaters, individual element PID control, pyrometer for true temperature
Pressure Forming
Vacuum + compressed air (6 bar) for fine detail reproduction on complex packaging geometries
Automatic Cutting & Stacking
Pneumatic punching with XY fine alignment, parts pushed onto conveyor by pneumatic pusher
Trim Winder
Automatic run-off of trimmed raw material for recycling
Technical Specifications
| Model | Forming Area | Forming Stroke | Punch Force |
|---|---|---|---|
| FCS-6090 | 600 x 900 mm | 200 mm (top) / 100 mm (bottom) | Up to 90 tonnes |
Compatible Materials
Typical FCS Applications
- — Fruit & Vegetable packaging
- — Food packaging trays & containers
- — Meal trays
- — Bakery & Confectionary containers
- — Dairy containers
- — Retail trays
- — Material handling trays
- — Medical device packaging
- — Electronics component trays
AM Series
Roll-Fed Forming Machines
The AM Series is a semi-automatic, simple to use roll-fed forming machine. Material is indexed from the heating oven into the forming station using a spike chain. Available in two variants: AM-V (vacuum only) and AM-P (air pressure up to 6 bar). The forming press is pneumatic or servo motor driven with a platen size of 500 x 600 mm. Once the shot is formed it is cut using a pneumatic shot cutter.
Machine Features
AM-V — Vacuum Only
Uses only vacuum to produce parts. Single heating oven on top side with IR lamps. Pneumatic driven forming press. Ideal for sub-contractors and OEMs producing simple vacuum formed parts from roll stock.
AM-P — Pressure Forming (up to 6 bar)
Uses air pressure up to 6 bar for deeper draws and finer detail. Pneumatic or servo motor driven press. Servo version achieves up to 25 cycles/min (wet) and 40 cycles/min (dry).
Spike Chain Indexing
Material is indexed from the heating oven into the forming station using a spike chain for precise, continuous sheet feeding.
Automatic Shot Cutting
Pneumatic shot cutter at exit. Each cavitation is separated using a separate hydraulic press as an off-line process.
PLC Control with HMI
Recipe storage and recall, production monitoring, diagnostics, safety interlocks and emergency stops.
Technical Specifications
| Specification | Details |
|---|---|
| Model | AM-V |
| Forming Area | 500 x 600 mm |
| Max Forming Depth | — |
| Max Sheet Width | 670 mm max |
| Sheet Thickness | 0.5 - 2.0 mm |
| Production Speed | Semi-automatic |
| Power Requirements | Pneumatic driven |
| Model | AM-P |
| Forming Area | 500 x 600 mm |
| Max Forming Depth | 60 mm |
| Max Sheet Width | 670 mm max |
| Sheet Thickness | 0.5 - 2.0 mm |
| Production Speed | Up to 25 cyc/min (servo) |
| Power Requirements | Pneumatic or Servo driven |
| Air Pressure | 6 bar, clean & dry |
| Ancillary Required | 5 ton Chiller + MTC, 20 HP 60 cfm Air Compressor |
Compatible Materials
Typical Applications
- — Thin gauge packaging for automotive parts
- — Deep draw containers and trays
- — Electronics packaging and inserts
- — Medical device packaging
- — Industrial component trays
Frequently Asked Questions.
Machinecraft manufactures custom vacuum forming machines ranging from compact 1000x600mm forming area up to XXL 6000x2200mm. Each machine is tailor-made to the customer's specific requirements, including forming area, draw depth, sheet thickness capacity, and automation level.
