Design of Special Machine for Deep Drawn Bed-LinerArchive entry · Mar 20, 2024Historical content; not current machine specifications or a production guarantee.How Machinecraft designed a specialized vacuum forming machine for deep drawn HDPE bed-liners for pickup trucks.When a leading North American pickup truck accessories manufacturer approached Machinecraft with the challenge of vacuum forming deep-drawn HDPE bed-liners, we knew this would require a machine unlike any we had built before. The bed-liner — a protective lining for the cargo bed of a pickup truck — demanded a forming depth of 1000mm with uniform wall thickness across a massive 3500 x 3500 mm forming area.The ChallengePickup truck bed-liners are among the most demanding vacuum forming applications. The part geometry requires extreme draw ratios — the depth-to-width ratio that determines how much the plastic sheet must stretch during forming. A typical bed-liner has complex contours including wheel well recesses, tailgate profiles, and ribbed floor patterns, all of which must maintain adequate wall thickness for durability.The material of choice — High Density Polyethylene (HDPE) — adds another layer of complexity. HDPE has a narrow forming window and tends to sag significantly during heating, making it difficult to achieve uniform temperature distribution across such a large sheet.Our Solution: PF1-XL-3535Machinecraft designed the PF1-XL-3535, a custom vacuum forming machine with a 3500 x 3500 mm forming area and 1000mm forming depth, specifically engineered for deep-drawn bed-liners. Key design features include:

Closed Chamber Design: A sealed forming chamber with pre-blow bubble forming. The bottom heater moves down to allow the heated sheet to sag in a controlled manner, while air pressure from below pre-stretches the sheet uniformly before it contacts the mold — ensuring consistent wall thickness even in deep-draw areas up to 1000mm.

Dual Zone Heating: Top and bottom infrared heater banks with individual zone control across hundreds of heating zones, allowing precise temperature profiling for HDPE\'s narrow forming window. The bottom heater retracts downward during the sag phase to provide clearance for controlled sheet droop.

Sheet Sag Detection: Infrared sensors continuously monitor sheet sag during the heating cycle, automatically adjusting heater output to prevent excessive sagging.

Servo-Driven Platen: A servo-controlled forming table with programmable speed profiles for optimal sheet-to-mold contact during the forming stroke.

ResultsFor deep-draw bedliner projects, evaluate wall-thickness requirements, material, tooling, heating, forming, cooling, trimming, and the production workflow with representative parts.This project demonstrates Machinecraft\'s ability to engineer custom solutions for the most demanding vacuum forming applications, combining our deep understanding of the thermoforming process with innovative machine design.Browse all archive entries
